Issue 1 of th June 2010Ģ 2 Using the System The PSU is located in the front offside locker area in caravans, and in similar locations in motorhomes. The unit houses fuses for the road lighting circuits and supplies from the tow vehicle, and also has connectors for the optional alarm system and Automatic Trailer Control (ATC) unit. Road Light Fuse Box - This small unit, which is unique to caravans, is located in the front offside bed box. This panel uses simple straightforward controls and reliable data communication to the PSU. The EC450 Series Control Panel (CP) - a remotely located user control panel used to turn circuits on and off and to display battery and water tank information. On caravan versions this unit also contains the provision for the Radio/CD head unit.
The system has a number of key components that you will need to be familiar with before attempting to use the system, these are: The EC450 Series Power Supply Unit (PSU) - a combined mains consumer unit and 12V controller located in the front locker. If you are unsure of any point please contact your dealer / distributor for advice before use.
Further technical details are contained in section 3 or in the supporting technical manual available from For the safe operation of all electrical equipment within your Leisure Vehicle it is important that you read and fully understand these instructions. 1 1 Introduction This section of the handbook will guide you through the operation of the electrical system.
